Hyundai Santa Fe Cm Workshop, Service and Repair Manual PDF (2006-2012)

Description

Hyundai Santa Fe CM Workshop, Service and Repair Manual PDF (2006-2012)

Why mechanics choose this manual

• Factory-authorized diagnostic procedures with live sensor data interpretation
• Complete ECU pinout diagrams and component testing protocols for all control modules
• Advanced CAN-bus network diagnostics with verified fault-finding trees
• Labor-saving repair sequences developed by certified Hyundai master technicians
• High-definition component layouts with factory torque specifications to 0.1 Nm
• Complete electrical schematics with module locations and connector face views
• OEM-specified maintenance intervals with fluid grade requirements
• Professional-grade PDF optimized for workshop conditions and mobile devices

What you will receive

Technical Coverage

Engines:
• Theta II 2.4L (G4KE) petrol – 174 hp/166 lb-ft
• Lambda II 3.5L (G6DC) V6 petrol – 276 hp/248 lb-ft
• R2.0 2.0L (D4HA) CRDi diesel – 150 hp/282 lb-ft
• R2.2 2.2L (D4HB) CRDi diesel – 197 hp/311 lb-ft

Transmissions:
• 6-speed manual (M6CF1) with dual-mass flywheel
• 6-speed automatic (A6MF1/A6LF1) with adaptive shift control
• SHIFTRONIC™ sequential mode with paddle shifters

Systems Covered:
• Engine management (MFI/CRDi) with full DTC coverage
• ABS/ESC/TCS with integrated yaw sensor calibration
• SRS airbag (9 modules) with OCS calibration
• Dual-zone climate control with refrigerant specifications
• Electric power steering (MDPS) with angle sensor reset
• AWD coupling with electronic torque distribution
• Smart key/immobilizer programming procedures

Frequently asked questions

Is this an official manual?
Yes, this is the genuine factory manual used by certified Hyundai technicians worldwide, including all 2012 technical service bulletin updates and revised specifications. Essential for warranty-compliant repairs.

Does it cover my specific engine or transmission?
Every powertrain combination for 2006-2012 Santa Fe CM models is covered with complete torque specifications, timing procedures, and diagnostic flowcharts. Includes special procedures for GDI and CRDi systems.

Do I need special software?
No specialized software required. Opens with any PDF reader and includes bookmarks for rapid navigation. Optimized for both workshop computers and tablets with high-contrast diagrams for clear viewing in all lighting conditions.

How detailed are the procedures?
Factory-level detail includes step-by-step repairs, component testing values, connector pin definitions, and diagnostic trouble code interpretation. Features actual technician notes from Hyundai’s training program for efficient troubleshooting.

Not affiliated with the vehicle manufacturer. Trademarks belong to their respective owners.
