Description

Yamaha WaveRunner XLT1200 Service Manual

This comprehensive service manual provides complete maintenance, repair, and troubleshooting procedures for Yamaha WaveRunner XLT1200 personal watercraft, powered by the Yamaha Marine 155HP 1131cc three-cylinder two-stroke engine (Model Code: 66V). Developed by Yamaha’s technical experts, this professional-grade manual delivers detailed instructions and specifications essential for proper servicing of all major systems.

Technical Coverage

• Complete engine service procedures for the 66V powerplant, including 5.0-5.2mm piston clearance specs, 14±0.4mm connecting rod alignment, and 0.75mm head gasket compression ratios
• Detailed fuel system maintenance including Mikuni SBN-44 carburetor specifications, 42L fuel tank service, and digital fuel injection system diagnostics (2.5-3.0 kg/cm² fuel pressure)
• Electrical system testing procedures with full wiring diagrams, CDI unit testing, and 12V DC system component locations
• SMC (Sheet Molding Compound) hull and deck repair methods including 2-layer FRP lamination techniques and hull thickness monitoring (minimum 4.5mm)
• 155mm Hyper-Flow jet pump service including 3-blade stainless steel impeller (15.6° pitch), wear ring clearance (0.5mm), and drive line alignment specifications
• KSUS (Kawasaki Smart Steering) system maintenance with 23° maximum steering angle and cable tension adjustment (2-3mm play)
• Complete cooling system service including dual-circuit water pump (6.9-7.1L/min flow rate) and 55°C thermostat testing

Professional Features

• Factory-specific torque specifications (cylinder head: 23 Nm, exhaust manifold: 20 Nm)
• Detailed exploded views and high-resolution diagrams of the 66V powerplant and KSUS steering system
• Step-by-step repair procedures with clear instructions for the Yamaha Total Engine Management (T.E.M.) system
• Comprehensive troubleshooting guides including digital fault code interpretation
• Critical safety information including Coast Guard compliance and navigation light requirements

Essential Resource

This manual serves as an indispensable resource for marine technicians, repair facilities, and experienced watercraft owners. The detailed technical information enables proper diagnosis and repair of complex systems, including the proprietary Yamaha Security System (Y.S.S.) and Multi-Function Digital Meters, helping maintain optimal performance and reliability of your XLT1200 WaveRunner. All procedures align with Yamaha’s factory specifications and recommended 50-hour service intervals.

Written by certified marine technicians, this manual ensures professional-quality repairs and maintenance procedures while helping prevent costly mistakes during complex service operations. Includes complete specifications for the 155HP power plant, 61.8L/min jet pump flow rate, and 3-person (240kg) capacity ratings.
